MIL-DTL-4710 Case Set, Transport And StorageThis specification covers case sets \(consisting of two cases\) for shipment and storage of miscellaneous small parts.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22


MIL-DTL-4710E
1.125
1.125
BODY BINDING (TYPICAL)
.0598 THICK STEEL
1.250
1.250
FRAGILE
THIS END UP
.500
LETTERS .750 HIGH
.094 ±.031 LINE WIDTH
DECAL OR STENCIL DETAIL
FIGURE 2
11
