MIL-DTL-4710E
CLOSURE BOLTS
.250 - 20 X .500 HEX HEAD - SLOTTED
SAE STD BOLT, ZINC PLATED,
WASHER TYPE GASKET
2 REQUIRED
RETAINED BY THREADS
1.250
ON BOLT
.625
CASE, LEFT HALF
TEE NUT - ZINC
Ø.312 HOLE
PLATED,
.625
IN FASTENER
2 REQUIRED.
FASTENED TO CASE
WITH TRUNK TACKS
1.000
1.625
OR RIVETS..
C CASE
L
TUBULAR
4.250
OR SOLID
RIVETS
CASE,
1.625
RIGHT HALF
BIFURCATED
FASTENER
RIVETS
.074 TO .080
THICK STEEL
2 REQUIRED
SECTION THRU FASTENER
FIGURE 4
13
