MIL-DTL-4710E
CASE, LEFT HALF
.125 +.031
.625 TYP. FOR HINGE
R .094 ±.016
THIS SIDE
TONGUE BINDING .060
1.375
THICK STEEL ALL
AROUND, CLOSE
.312
FITTING MITERED
.625
L
C CASE
TYP. FOR HINGE
.875
JOINTS AT CORNERS.
THIS SIDE
1.125
INNER GROOVE
TUBULAR OR SOLID RIVET - Ø.141 MIN.
BINDING .060 THICK
4 MIN. PER HINGE.
STEEL, ONE PIECE.
JOINT UNDER CENTER
OUTER GROOVE BINDING .060
HINGE.
THICK STEEL 1.375 WIDE, ONE PEICE.
JOINT UNDER CENTER HINGE.
.438 (REF)
HINGE .070 TO .080 THICK STEEL,
8.000 ±.500 LONG OPEN, 1.625 ±.500 MAX.
GASKET .250 X .438
WIDTH, 3 REQUIRED.
CONTINUOUS ALL
AROUND OR CLOSE
.141 BIFURCATED RIVETS WITH Ø.312 HEAD,
FITTING 45° ANGLE
4 REQUIRED
BUTT JOINT. CEMENT
CASE, RIGHT HALF
TO RIGHT HALF OF CASE.
SECTION THRU HINGE
FIGURE 3
12
